Intelligent Key System Symptoms

Symptom Table

NOTE:

Perform the self-diagnosis with CONSULT before the symptom diagnosis. Perform the trouble diagnosis if any DTC is detected.

SYMPTOM TABLE 1 (BOTH INTELLIGENT KEYS HAVE THE SAME SYMPTOMS)

No.	Door lock operation (remote keyless entry)	Door lock operation (one touch sensor or request switch of front/rear/back door) or trunk/back door open operation (opener switch of trunk/back door panel)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key is within the detection area of inside key antenna)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key placed next to power switch)	Unlock operation when approaching the Nissan Ariya vehicle, lock operation when away from the vehicle (registered Intelligent Key is within the detection area of outside key antenna)	Symptom
1	OK	OK	Not set to READY	Not set to READY	OK	Diagnosis Procedure
2	OK	NG	OK	OK	OK	Diagnosis Procedure
3	OK	NG	Not set to READY	OK	OK	Diagnosis Procedure
4	NG	NG	Not set to READY	OK	OK	Diagnosis Procedure
5	NG	NG	Not set to READY	Not set to READY	NG	Diagnosis Procedure
6	OK	OK	Not set to READY	OK	OK	Diagnosis Procedure
7	NG	OK	OK	OK	OK	Diagnosis Procedure
8	NG	NG	OK	OK	OK	Diagnosis Procedure
9	Poor range	OK	OK	OK	OK	Diagnosis Procedure
10	OK	OK	OK	OK	NG	Diagnosis Procedure

SYMPTOM TABLE 2 (ONE INTELLIGENT KEY HAS THE SYMPTOM, OTHER KEYS OPERATE NORMALLY)

No.	Door lock operation (remote keyless entry)	Door lock operation (one touch sensor or request switch of front/rear/back door) or trunk/back door open operation (opener switch of trunk/back door panel)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key is within the detection area of inside key antenna)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key placed next to power switch)	Unlock operation when approaching the Nissan Ariya vehicle, lock operation when away from the vehicle (registered Intelligent Key is within the detection area of outside key antenna)	Symptom
1	NG	OK	OK	OK	OK	Diagnosis Procedure
2	NG	NG	Not set to READY	OK	OK	Diagnosis Procedure
3	NG	NG	Not set to READY	Not set to READY	NG	Diagnosis Procedure
4	OK	OK	Not set to READY	Not set to READY	OK	Diagnosis Procedure
5	OK	NG	Not set to READY	OK	OK	Diagnosis Procedure
6	Poor range	OK	OK	OK	OK	Diagnosis Procedure
7	OK	OK	OK	OK	NG	Diagnosis Procedure

All Doors Do Not Lock/unlock or Trunk/back Door Do Not Open with One Touch Sensor and Request Switch

Description

All doors do not lock/unlock using door request switch and one touch sensor.

NOTE:

Before starting diagnosis check that vehicle condition is as shown in “Conditions of Nissan Ariya vehicle”, and check each symptom.

SYMPTOM TABLE (BOTH INTELLIGENT KEYS HAVE THE SAME SYMPTOMS)

Door lock operation (remote keyless entry)	Door lock operation (one touch sensor or request switch of front/rear/back door) or trunk/back door open operation (opener switch of trunk/back door panel)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key is within the detection area of inside key antenna)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key placed next to power switch)	Unlock operation when approaching the Nissan Ariya vehicle, lock operation when away from the vehicle (registered Intelligent Key is within the detection area of outside key antenna)
OK	NG	OK	OK	OK

CONDITIONS OF VEHICLE (OPERATING CONDITIONS)

• “Ext Door Switch ” of the vehicle setting in the combination meter is ON.

• Registered Intelligent Key is within the detection area of outside key antenna.

DIAGNOSIS PROCEDURE

Refer to Diagnosis Procedure.

Diagnosis Procedure

CHECK INTELLIGENT KEY SYSTEM SYMPTOM TABLE

Check Intelligent Key system symptom table.

Refer to Symptom Table.

>>

GO TO 2.

PERFORM SELF-DIAGNOSIS RESULT

Select “Self Diagnostic Result” mode of “INTELLIGENT KEY”, and check if DTC is detected.

Is DTC detected?

YES>>

Perform the trouble diagnosis for detected DTC.

NO>>

GO TO 3.

CHECK OUTSIDE KEY ANTENNA

Use SIGNAL TECH II to check each outside key antenna. For the inspection method and how to use SIGNAL TECH II, refer to “NISSAN/INFINITI SIGNAL TECH II USER GUIDE”.

Is the inspection result normal?

YES>>

GO TO 4.

NO>>

Repair or replace the malfunctioning parts.

CHECK INTELLIGENT KEY OUTPUT SIGNAL

Use SIGNAL TECH II to check Intelligent Key outside signal. For the inspection method and how to use SIGNAL TECH II, refer to “NISSAN/INFINITI SIGNAL TECH II USER GUIDE”.

Is the inspection result normal?

YES>>

GO TO 5.

NO>>

Repair or replace the malfunctioning parts.

CHECK ONE TOUCH SENSOR

Check one touch sensor.

• Front LH: Refer to DTC Diagnosis Procedure.

• Front RH: Refer to DTC Diagnosis Procedure.

• Rear LH: Refer to DTC Diagnosis Procedure.

• Rear RH: Refer to DTC Diagnosis Procedure.

Is the inspection result normal?

YES>>

GO TO 6.

NO>>

Repair or replace the malfunctioning parts.

CHECK BACK DOOR REQUEST SWITCH

Check door request switch. Refer to DTC Diagnosis Procedure.

Is the inspection result normal?

YES>>

GO TO 7.

NO>>

Repair or replace the malfunctioning parts.

REPLACE INTELLIGENT KEY UNIT

1. Replace Intelligent Key unit. Refer to Removal and Installation.

2. Check operation after replacement.

Is the inspection result normal?

YES>>

INSPECTION END

NO>>

Check intermittent incident. Refer to Intermittent Incident.

Door Does Not Lock/unlock and Vehicle Cannot Be Set to Ready (one Touch Sensor/req Sw/push Sw) (all Keys)

Description

All doors do not lock/unlock using one touch sensor, door request switch and cannot vehicle set to READY when power switch is pressed while carrying Intelligent Key.

SYMPTOM TABLE (BOTH INTELLIGENT KEYS HAVE THE SAME SYMPTOMS)

Door lock operation (remote keyless entry)	Door lock operation (one touch sensor or request switch of front/rear/back door) or trunk/back door open operation (opener switch of trunk/back door panel)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key is within the detection area of inside key antenna)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key placed next to power switch)	Unlock operation when approaching the Nissan Ariya vehicle, lock operation when away from the vehicle (registered Intelligent Key is within the detection area of outside key antenna)
OK	NG	Not set to READY	OK	OK

DIAGNOSIS PROCEDURE

Refer to Diagnosis Procedure.

Diagnosis Procedure

CHECK INTELLIGENT KEY SYSTEM SYMPTOM TABLE

Check Intelligent Key system symptom table.

Refer to Symptom Table.

>>

GO TO 2.

CHECK INSIDE KEY ANTENNA

Use SIGNAL TECH II to check each inside key antenna. For the inspection method and how to use SIGNAL TECH II, refer to “NISSAN/INFINITI SIGNAL TECH II USER GUIDE”.

Is the inspection result normal?

YES>>

GO TO 3.

NO>>

Repair or replace the malfunctioning parts.

CHECK OUTSIDE KEY ANTENNA

Use SIGNAL TECH II to check each outside key antenna. For the inspection method and how to use SIGNAL TECH II, refer to “NISSAN/INFINITI SIGNAL TECH II USER GUIDE”.

Is the inspection result normal?

YES>>

GO TO 4.

NO>>

Repair or replace the malfunctioning parts.

REGISTER INTELLIGENT KEY

1. Register the Intelligent Key again.

2. Check operation after replacement.

Is the inspection result normal?

YES>>

INSPECTION END

NO>>

GO TO 5.

REPLACE INTELLIGENT KEY

1. Replace the Intelligent Key and perform registration again.

2. Check operation after replacement.

Is the inspection result normal?

YES>>

INSPECTION END

NO>>

GO TO 6.

REPLACE INTELLIGENT KEY UNIT

1. Replace Intelligent Key unit. Refer to Removal and Installation.

2. Check operation after replacement.

Is the inspection result normal?

YES>>

INSPECTION END

NO>>

Check intermittent incident. Refer to Intermittent Incident.

Door Does Not Lock/unlock and Vehicle Cannot Be Set to Ready (all I-Key/one Touch Sensor/req Sw/push Sw)

Description

All doors do not lock/unlock using one touch sensor, door request switch and cannot vehicle set to READY when power switch is pressed while carrying Intelligent Key.

SYMPTOM TABLE (BOTH INTELLIGENT KEYS HAVE THE SAME SYMPTOMS)

Door lock operation (remote keyless entry)	Door lock operation (one touch sensor or request switch of front/rear/back door) or trunk/back door open operation (opener switch of trunk/back door panel)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key is within the detection area of inside key antenna)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key placed next to power switch)	Unlock operation when approaching the Nissan Ariya vehicle, lock operation when away from the vehicle (registered Intelligent Key is within the detection area of outside key antenna)
NG	NG	Not set to READY	OK	OK

DIAGNOSIS PROCEDURE

Refer to Diagnosis Procedure.

Diagnosis Procedure

CHECK INTELLIGENT KEY SYSTEM SYMPTOM TABLE

Check Intelligent Key system symptom table.

Refer to Symptom Table.

>>

GO TO 2.

CHECK INTELLIGENT KEY BATTERY

Check Intelligent Key battery.

Refer to Component Inspection.

Is the inspection result normal?

YES>>

GO TO 3.

NO>>

Repair or replace the malfunctioning parts.

REPLACE INTELLIGENT KEY UNIT

1. Replace Intelligent Key unit. Refer to Removal and Installation.

2. Check operation after replacement.

Is the inspection result normal?

YES>>

INSPECTION END

NO>>

Check intermittent incident. Refer to Intermittent Incident.

Intelligent Key System All Functions Cannot Operate (all Keys)

Description

Intelligent Key system all functions cannot operate (door lock and vehicle set to READY).

SYMPTOM TABLE (BOTH INTELLIGENT KEYS HAVE THE SAME SYMPTOMS)

Door lock operation (remote keyless entry)	Door lock operation (one touch sensor or request switch of front/rear/back door) or trunk/back door open operation (opener switch of trunk/back door panel)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key is within the detection area of inside key antenna)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key placed next to power switch)	Unlock operation when approaching the Nissan Ariya vehicle, lock operation when away from the vehicle (registered Intelligent Key is within the detection area of outside key antenna)
NG	NG	Not set to READY	Not set to READY	NG

DIAGNOSIS PROCEDURE

Refer to Diagnosis Procedure.

Diagnosis Procedure

CHECK INTELLIGENT KEY SYSTEM SYMPTOM TABLE

Check Intelligent Key system symptom table.

Refer to Symptom Table.

>>

GO TO 2.

CHECK INTELLIGENT KEY-1

For both Intelligent Key that cannot be used for door lock and unlock, check that the Intelligent Key belongs to the Nissan Ariya vehicle to be checked.

• Check if the Intelligent Key that is checked is the Intelligent Key for a different INFINITI Nissan Ariya vehicle that the user owns.

• Check that the Intelligent Key buttons match the vehicle specifications.

Does the Intelligent Key belong to the Nissan Ariya vehicle to be checked?

YES>>

GO TO 3.

NO>>

Check Intelligent Key button operation using a registered Intelligent Key that belongs to the Nissan Ariya vehicle.

CHECK INTELLIGENT KEY-2

Check the inside of the both Intelligent Key for rust or corrosion by water. Simultaneously check the internal circuits for damage.

Is the inspection result normal?

YES>>

GO TO 4.

NO>>

Replace Intelligent Key.

REGISTER INTELLIGENT KEY

1. Register the Intelligent Key again.

2. Check operation after replacement.

Is the inspection result normal?

YES>>

INSPECTION END

NO>>

GO TO 5.

REPLACE INTELLIGENT KEY

1. Replace the Intelligent Key and perform registration again.

2. Check operation after replacement.

Is the inspection result normal?

YES>>

INSPECTION END

NO>>

GO TO 6.

REPLACE INTELLIGENT KEY UNIT

1. Replace Intelligent Key unit. Refer to Removal and Installation.

2. Check the operation after replacement.

Is the inspection result normal?

YES>>

INSPECTION END

NO>>

Check intermittent incident. Refer to Intermittent Incident.

Door Does Not Lock/unlock with Intelligent Key

Description

All doors do not lock/unlock using Intelligent Key button.

NOTE:

Before starting diagnosis check that vehicle condition is as shown in “Conditions of Nissan Ariya vehicle”, and check each symptom.

SYMPTOM TABLE (BOTH INTELLIGENT KEYS HAVE THE SAME SYMPTOMS)

Door lock operation (remote keyless entry)	Door lock operation (one touch sensor or request switch of front/rear/back door) or trunk/back door open operation (opener switch of trunk/back door panel)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key is within the detection area of inside key antenna)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key placed next to power switch)	Unlock operation when approaching the Nissan Ariya vehicle, lock operation when away from the vehicle (registered Intelligent Key is within the detection area of outside key antenna)
NG	OK	OK	OK	OK

CONDITIONS OF VEHICLE (OPERATING CONDITIONS)

Registered Intelligent Key is within the detection area of remote keyless entry receiver.

DIAGNOSIS PROCEDURE

Refer to Diagnosis Procedure.

Diagnosis Procedure

CHECK INTELLIGENT KEY SYSTEM SYMPTOM TABLE

Check Intelligent Key system symptom table.

Refer to Symptom Table.

>>

GO TO 2.

CHECK INTELLIGENT KEY OUTPUT SIGNAL

Use SIGNAL TECH II to check Intelligent Key output signal. For the inspection method and how to use SIGNAL TECH II, refer to “NISSAN/INFINITI SIGNAL TECH II USER GUIDE”.

Is the inspection result normal?

YES>>

Replace Intelligent Key unit. Refer to Removal and Installation.

NO>>

Replace Intelligent Key.

Intelligent Key Button Operation Has Poor Range (all Keys)

Description

Intelligent Key button operation has poor range.

SYMPTOM TABLE (BOTH INTELLIGENT KEYS HAVE THE SAME SYMPTOMS)

Door lock operation (remote keyless entry)	Door lock operation (one touch sensor or request switch of front/rear/back door) or trunk/back door open operation (opener switch of trunk/back door panel)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key is within the detection area of inside key antenna)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key placed next to power switch)	Unlock operation when approaching the Nissan Ariya vehicle, lock operation when away from the vehicle (registered Intelligent Key is within the detection area of outside key antenna)
Poor range	OK	OK	OK	OK

DIAGNOSIS PROCEDURE

Refer to Diagnosis Procedure.

Diagnosis Procedure

CHECK INTELLIGENT KEY SYSTEM SYMPTOM TABLE

Check Intelligent Key system symptom table.

Refer to Symptom Table.

>>

GO TO 2.

CHECK INTELLIGENT KEY LOW BATTERY WARNING

Check that the Intelligent Key low battery warning operates.

Is the Intelligent Key low battery warning operated?

YES>>

GO TO 3.

NO>>

Replace Intelligent Key battery. Refer to Removal and Installation.

CHECK INTELLIGENT KEY BATTERY

Check the Intelligent Key battery.

Refer to Component Inspection.

Is the inspection result normal?

YES>>

GO TO 4.

NO>>

Replace Intelligent Key battery. Refer to Removal and Installation.

REMOTE AFTERMARKET DEVICE

1. If the Nissan Ariya vehicle is equipped with any interference-generating aftermarket device such as a vehicle security system, charger and remote engine starter etc., remove them.

2. Check operation after replacement.

Is the inspection result normal?

YES>>

INSPECTION END

NO>>

GO TO 5.

REPLACE INTELLIGENT KEY UNIT

1. Replace Intelligent Key unit. Refer to Removal and Installation.

2. Check operation after replacement.

Is the inspection result normal?

YES>>

INSPECTION END

NO>>

Check intermittent incident. Refer to Intermittent Incident.

Door Does Not Lock/unlock with Intelligent Key (one Key)

Description

All doors do not lock/unlock using Intelligent Key button. (One Intelligent Key has the symptom, other keys operate normally.)

SYMPTOM TABLE (ONE INTELLIGENT KEY HAS THE SYMPTOM, OTHER KEYS OPERATE NORMALLY)

Door lock operation (remote keyless entry)	Door lock operation (one touch sensor or request switch of front/rear/back door) or trunk/back door open operation (opener switch of trunk/back door panel)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key is within the detection area of inside key antenna)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key placed next to power switch)	Unlock operation when approaching the Nissan Ariya vehicle, lock operation when away from the vehicle (registered Intelligent Key is within the detection area of outside key antenna)
NG	OK	OK	OK	OK

DIAGNOSIS PROCEDURE

Refer to Diagnosis Procedure.

Diagnosis Procedure

CHECK INTELLIGENT KEY SYSTEM SYMPTOM TABLE

Check Intelligent Key system symptom table.

Refer to Symptom Table.

>>

GO TO 2.

CHECK INTELLIGENT KEY OUTPUT SIGNAL

Use SIGNAL TECH II to check Intelligent Key output signal. For the inspection method and how to use SIGNAL TECH II, refer to “NISSAN/INFINITI SIGNAL TECH II USER GUIDE”.

YES>>

GO TO 3

NO>>

Replace Intelligent Key.

REGISTER INTELLIGENT KEY

1. Register the Intelligent Key again.

2. Check operation after replacement.

Is the inspection result normal?

YES>>

INSPECTION END

NO>>

GO TO 4.

REPLACE INTELLIGENT KEY

1. Replace the Intelligent Key and perform registration again.

2. Check operation after replacement.

Is the inspection result normal?

YES>>

INSPECTION END

NO>>

GO TO 5.

REPLACE INTELLIGENT KEY UNIT

1. Replace Intelligent Key unit. Refer to Removal and Installation.

2. Check operation after replacement.

Is the inspection result normal?

YES>>

INSPECTION END

NO>>

Check intermittent incident. Refer to Intermittent Incident.

Door Does Not Lock/unlock and Vehicle Cannot Be Set to Ready (one I-Key/one Touch Sensor/req Sw/push Sw)

Description

All doors do not lock/unlock using one touch sensor, door request switch and cannot vehicle set to READY when power switch is pressed while carrying Intelligent Key. (One Intelligent Key has the symptom, other keys operate normally.)

SYMPTOM TABLE (ONE INTELLIGENT KEY HAS THE SYMPTOM, OTHER KEYS OPERATE NORMALLY)

Door lock operation (remote keyless entry)	Door lock operation (one touch sensor or request switch of front/rear/back door) or trunk/back door open operation (opener switch of trunk/back door panel)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key is within the detection area of inside key antenna)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key placed next to power switch)	Unlock operation when approaching the Nissan Ariya vehicle, lock operation when away from the vehicle (registered Intelligent Key is within the detection area of outside key antenna)
NG	NG	Not set to READY	OK	OK

DIAGNOSIS PROCEDURE

Refer to Diagnosis Procedure.

Diagnosis Procedure

CHECK INTELLIGENT KEY SYSTEM SYMPTOM TABLE

Check Intelligent Key system symptom table.

Refer to Symptom Table.

>>

GO TO 2.

CHECK INTELLIGENT KEY

Check the inside of the Intelligent Key for rust or corrosion by water. Simultaneously check the internal circuits for damage. Squeeze, twist or bend the Intelligent Key and check the functionality again. Is the Intelligent Key operating normally?

Is the inspection result normal?

YES>>

GO TO 3.

NO>>

Replace Intelligent Key.

CHECK INTELLIGENT KEY BATTERY

Check the Intelligent Key battery.

Refer to Component Inspection.

Is the inspection result normal?

YES>>

GO TO 4.

NO>>

Replace Intelligent Key battery. Refer to Removal and Installation.

REGISTER INTELLIGENT KEY

1. Register the Intelligent Key again.

2. Check operation after replacement.

Is the inspection result normal?

YES>>

INSPECTION END

NO>>

GO TO 5.

REPLACE INTELLIGENT KEY

1. Replace the Intelligent Key and perform registration again.

2. Check operation after replacement.

Is the inspection result normal?

YES>>

INSPECTION END

NO>>

GO TO 6.

REPLACE INTELLIGENT KEY UNIT

1. Replace Intelligent Key unit. Refer to Removal and Installation.

2. Confirm the operation after replacement.

Is the inspection result normal?

YES>>

INSPECTION END

NO>>

Check intermittent incident. Refer to Intermittent Incident.

Intelligent Key Button Operation Has Poor Range (one Key)

Description

Intelligent Key button operation has poor range. (One Intelligent Key has the symptom, other keys operate normally.)

SYMPTOM TABLE (ONE INTELLIGENT KEY HAS THE SYMPTOM, OTHER KEYS OPERATE NORMALLY)

Door lock operation (remote keyless entry)	Door lock operation (one touch sensor or request switch of front/rear/back door) or trunk/back door open operation (opener switch of trunk/back door panel)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key is within the detection area of inside key antenna)	Nissan Ariya Vehicle set to READY with power switch operation (registered Intelligent Key placed next to power switch)	Unlock operation when approaching the Nissan Ariya vehicle, lock operation when away from the vehicle (registered Intelligent Key is within the detection area of outside key antenna)
Poor range	OK	OK	OK	OK

DIAGNOSIS PROCEDURE

Refer to Diagnosis Procedure.

Diagnosis Procedure

CHECK INTELLIGENT KEY SYSTEM SYMPTOM TABLE

Check Intelligent Key system symptom table.

Refer to Symptom Table.

>>

GO TO 2.

CHECK INTELLIGENT KEY LOW BATTERY WARNING

Check that the Intelligent Key low battery warning operates.

Is the Intelligent Key low battery warning operated?

YES>>

Replace Intelligent Key battery. Refer to Removal and Installation.

NO>>

GO TO 3.

CHECK INTELLIGENT KEY BATTERY

Check the Intelligent Key battery. Refer to Component Inspection.

Is the inspection result normal?

YES>>

Replace Intelligent Key and register new Intelligent Key.

NO>>

Replace Intelligent Key battery. Refer to Removal and Installation.

Automatic Back Door Functions Do Not Cancel

Diagnosis Procedure

CHECK “POWER BACK DOOR SETTING” IN COMBINATION METER

Check “Power back door setting” of the Nissan Ariya vehicle setting in the combination meter is OFF.

Is the inspection result normal?

YES>>

GO TO 2.

NO>>

Set “Power back door setting” to “OFF”.

REPLACE AUTOMATIC BACK DOOR CONTROL UNIT

1. Replace automatic back door control unit. Refer to Removal and Installation.

2. Confirm the operation after replacement.

Is the result normal?

YES>>

INSPECTION END

NO>>

Check intermittent incident. Refer to Intermittent Incident.

Automatic Back Door Warning Does Not Operate

Description

Automatic back door warning buzzer does not operate when automatic back door warning function are performed.

Diagnosis Procedure

CHECK AUTOMATIC BACK DOOR WARNING BUZZER

Check automatic back door warning buzzer.

Refer to DTC Diagnosis Procedure.

Is the inspection result normal?

YES>>

GO TO 2.

NO>>

Repair or replace the malfunctioning parts.

REPLACE AUTOMATIC BACK DOOR CONTROL UNIT

1. Replace automatic back door control unit. Refer to Removal and Installation.

2. Confirm the operation after replacement.

Is the result normal?

YES>>

INSPECTION END

NO>>

Check intermittent incident. Refer to Intermittent Incident.

Automatic Back Door Anti-Pinch Function Does Not Operate

Diagnosis Procedure

CHECK DTC WITH AUTOMATIC BACK DOOR CONTROL UNIT

Check that DTC is not detected with automatic back door control unit.

Is the inspection result normal?

YES>>

GO TO 2.

NO>>

Refer to DTC Index.

CHECK TOUCH SENSOR LH

Check touch sensor LH.

Refer to DTC Diagnosis Procedure.

Is the inspection result normal?

YES>>

GO TO 3.

NO>>

Repair or replace the malfunctioning parts.

CHECK TOUCH SENSOR RH

Check touch sensor RH.

Refer to DTC Diagnosis Procedure.

Is the inspection result normal?

YES>>

GO TO 4.

NO>>

Repair or replace the malfunctioning parts.

REPLACE AUTOMATIC BACK DOOR CONTROL UNIT

1. Replace automatic back door control unit. Refer to Removal and Installation.

2. Confirm the operation after replacement.

Is the result normal?

YES>>

INSPECTION END

NO>>

Check intermittent incident. Refer to Intermittent Incident.

Auto Door Lock Operation Does Not Operate

Diagnosis Procedure

REPLACE BCM

1. Replace BCM. Refer to Removal and Installation.

2. Confirm the operation after replacement.

Is the result normal?

YES>>

INSPECTION END

NO>>

Check intermittent incident. Refer to Intermittent Incident.

Back Door Auto Closure Function Does Not Operate

Diagnosis Procedure

CHECK DTC WITH AUTOMATIC BACK DOOR CONTROL UNIT

Check that DTC is not detected with automatic back door control unit.

Is the inspection result normal?

YES>>

GO TO 2.

NO>>

Refer to DTC Index.

CHECK OPEN SWITCH

Check open switch.

Refer to DTC Diagnosis Procedure.

Is the inspection result normal?

YES>>

GO TO 3.

NO>>

Repair or replace the malfunctioning parts.

CHECK CLOSE SWITCH

Check close switch.

Refer to DTC Diagnosis Procedure.

Is the inspection result normal?

YES>>

GO TO 4.

NO>>

Repair or replace the malfunctioning parts.

CHECK HALF LATCH SWITCH

Check half latch switch.

Refer to DTC Diagnosis Procedure.

Is the inspection result normal?

YES>>

GO TO 5.

NO>>

Repair or replace the malfunctioning parts.

CHECK BACK DOOR CLOSURE MOTOR

Check back door closure motor.

Refer to DTC Diagnosis Procedure.

Is the inspection result normal?

YES>>

GO TO 6.

NO>>

Repair or replace the malfunctioning parts.

REPLACE BACK DOOR LOCK ASSEMBLY

1. Replace back door lock assembly.

2. Confirm the operation after replacement.

Is the inspection result normal?

YES>>

INSPECTION END

NO>>

GO TO 7.

REPLACE AUTOMATIC BACK DOOR CONTROL UNIT

1. Replace automatic back door control unit. Refer to Removal and Installation.

2. Confirm the operation after replacement.

Is the inspection result normal?

YES>>

INSPECTION END

NO>>

Check intermittent incident. Refer to Intermittent Incident.

Door Lock Operation Warning Does Not Operate

Diagnosis Procedure

CHECK DOOR LOCK FUNCTION

Check door lock using one touch sensor or Intelligent Key.

Does door lock with one touch sensor or Intelligent Key?

YES>>

GO TO 2.

NO>>

Refer to Symptom Table.

CHECK INTELLIGENT KEY WARNING BUZZER

Check Intelligent Key warning buzzer.

Refer to Diagnosis Procedure.

Is the inspection result normal?

YES>>

GO TO 3.

NO>>

Repair or replace the malfunctioning parts.

REPLACE INTELLIGENT KEY UNIT

1. Replace Intelligent Key unit. Refer to Removal and Installation.

2. Confirm the operation after replacement.

Is the result normal?

YES>>

INSPECTION END

NO>>

Check intermittent incident. Refer to Intermittent Incident.

Intelligent Key Low Battery Warning Does Not Operate

Diagnosis Procedure

CHECK INTELLIGENT KEY BATTERY

Check Intelligent Key battery.

Refer to Component Inspection.

Is the inspection result normal?

YES>>

GO TO 2.

NO>>

Repair or replace the malfunctioning parts.

CHECK INSIDE KEY ANTENNA

Check inside key antenna. Refer to DTC Diagnosis Procedure.

Is the inspection result normal?

YES>>

GO TO 3.

NO>>

Repair or replace the malfunctioning parts.

REPLACE INTELLIGENT KEY UNIT

1. Replace Intelligent Key unit. Refer to Removal and Installation.

2. Confirm the operation after replacement.

Is the result normal?

YES>>

INSPECTION END

NO>>

Check intermittent incident. Refer to Intermittent Incident.

Power Off Interlock Door Unlock Function Does Not Operate

Diagnosis Procedure

CHECK “AUTO DOOR UNLOCK” SETTING IN COMBINATION METER

Check “Auto Door Unlock” setting is “Power OFF”.

Is the inspection result normal?

YES>>

GO TO 2.

NO>>

Set “Power OFF” in combination meter.

REPLACE BCM

1. Replace BCM. Refer to Removal and Installation.

2. Confirm the operation after replacement.

Is the result normal?

YES>>

INSPECTION END

NO>>

Check intermittent incident. Refer to Intermittent Incident.

Key Reminder Function Does Not Operate

Diagnosis Procedure

CHECK DOOR SWITCH

Check door switch.

Refer to Component Function Check.

Is the inspection result normal?

YES>>

GO TO 2.

NO>>

Repair or replace the malfunctioning parts.

CHECK UNLOCK SENSOR

Check unlock sensor.

Refer to Diagnosis Procedure.

Is the inspection result normal?

YES>>

GO TO 3.

NO>>

Repair or replace the malfunctioning parts.

CHECK INSIDE KEY ANTENNA

Check inside key antenna. Refer to DTC Diagnosis Procedure.

Is the inspection result normal?

YES>>

GO TO 4.

NO>>

Repair or replace the malfunctioning parts.

REPLACE INTELLIGENT KEY UNIT

1. Replace Intelligent Key unit. Refer to Removal and Installation.

2. Confirm the operation after replacement.

Is the result normal?

YES>>

INSPECTION END

NO>>

Check intermittent incident. Refer to Intermittent Incident.

Normal Operating Condition

Symptom Description

• When the back door position is in the range of [between "just before fully closed" and the position approximately less than 150 mm (5.91 in) from "just before fully closed" ], the back door does not operate even if any of switches are operated.

• To operate the back door by switches, manually close the back door to "Fully closed" position or manually open the back door approximately more than 150 mm (5.91 in) from the position of "Just before fully closed". And then operate any of switches.

Squeak and Rattle Trouble Diagnoses

Work Flow

CUSTOMER INTERVIEW

Interview the customer if possible, to determine the conditions that exist when the noise occurs. Use the Diagnostic Worksheet during the interview to document the facts and conditions when the noise occurs and any customer comments. Refer to Diagnostic Worksheet. This information is necessary to duplicate the conditions that exist when the noise occurs.

• The customer may not be able to provide a detailed description or the location of the noise. Attempt to obtain all the facts and conditions that exist when the noise occurs (or does not occur).

• If there is more than one noise in the Nissan Ariya vehicle, perform a diagnosis and repair the noise that the customer is concerned about. This can be accomplished by performing a test drive with the customer.

• After identifying the type of noise, isolate the noise in terms of its characteristics. The noise characteristics are provided so that the customer, service adviser, and technician use the same language when describing the noise.

• Squeak – (Like tennis shoes on a clean floor)

  Squeak characteristics include the light contact / fast movement / brought on by road conditions / hard surfaces = high-pitched noise / softer surfaces = low-pitched noises / edge to surface = chirping

• Creak – (Like walking on an old wooden floor)

  Creak characteristics include firm contact / slow movement/twisting with a rotational movement / pitch dependent on materials / often brought on by activity.

• Rattle – (Like shaking a baby rattle)

  Rattle characteristics include fast repeated contact / vibration or similar movement / loose parts/missing clip or fastener / incorrect clearance.

• Knock – (Like a knock on a door)

  Knock characteristics include hollow sounds / sometimes repeating / often brought on by driver action.

• Tick – (Like a clock second hand)

  Tick characteristics include gentle contacting of light materials / loose components / can be caused by driver

  action or road conditions.

• Thump – (Heavy, muffled knock noise)

  Thump characteristics include softer knock / dull sounds often brought on by activity.

• Buzz – (Like a bumblebee)

  Buzz characteristics include high frequency rattle / firm contact.

• Often the degree of acceptable noise level varies depending upon the person. A noise that a technician may judge as acceptable may be very irritating to a customer.

• Weather conditions, especially humidity and temperature, may have a great effect on noise level.

DUPLICATE THE NOISE AND TEST DRIVE

If possible, drive the vehicle with the customer until the noise is duplicated. Note any additional information on the Diagnostic Worksheet regarding the conditions or location of the noise. This information can be used to duplicate the same conditions when the repair is reconfirmed.

If the noise can be duplicated easily during the test drive, do the following with the vehicle stopped to help identify the source of the noise.

1) Close a door.

2) Tap or push/pull around the area where the noise appears to be coming from.

3) Rev the engine.

4) Use a floor jack to recreate vehicle “twist”.

5) At idle, apply engine load (electrical load, half-clutch on M/T models, drive position on A/T models).

6) Raise the vehicle on a hoist and hit a tire with a rubber hammer.

• Drive the vehicle and attempt to duplicate the conditions the customer states exist when the noise occurs.

• If it is difficult to duplicate the noise, drive the Nissan Ariya vehicle slowly on an undulating or rough road to stress the vehicle body.

CHECK RELATED SERVICE BULLETINS

After verifying the customer concern or symptom, check ASIST for Technical Service Bulletins (TSBs) related to the concern or symptom.

If a TSB relates to the symptom, follow the procedure to repair the noise.

LOCATE THE NOISE AND IDENTIFY THE ROOT CAUSE

1. Narrow down the noise to a general area. To help pinpoint the source of the noise, use a listening tool (Chassis ear: J-39570, engine ear, and mechanics stethoscope).

2. Narrow down the noise to a more specific area and identify the cause of the noise by:

• Removing the component(s) in the area(s) that you suspect to be the cause of the noise.

  Do not use too much force when removing clips and fasteners, otherwise clips and fasteners can be broken or lost during the repair, creating a new noise.

• Tapping or pushing/pulling the component(s) that you suspect to be the cause of the noise.

  Do not tap or push/pull the component(s) with excessive force, otherwise the noise is eliminated only temporarily.

• Feeling for a vibration by hand by touching the component(s) that is (are) suspected to be the cause of the noise.

• Placing a piece of paper between components that you suspect to be the cause of the noise.

• Looking for loose components and contact marks.

  Refer to Inspection Procedure.

REPAIR THE CAUSE

• If the cause is a loose component, tighten the component securely.

• If the cause is insufficient clearance between components:

  • Separate components by repositioning or loosening and retightening the components, if possible.

  • Insulate components with a suitable insulator such as urethane pads, foam blocks, felt cloth tape, or urethane tape. A NISSAN Squeak and Rattle Kit (J-50397) is available through the authorized NISSAN Parts Department.

CAUTION:

Never use excessive force as many components are constructed of plastic and may be damaged.

NOTE:

Always check with the Parts Department for the latest parts information.

The following materials are contained in the NISSAN Squeak and Rattle Kit (J-50397) are listed on the inside cover of the kit; and can each be ordered separately as needed.

URETHANE PADS [1.5 mm (0.059 in) thick]

Insulates connectors, harness, etc.

• 76268-9E005: 100 × 135 mm (3.937 × 5.315 in)

• 76884-71L01: 60 × 85 mm (2.362 × 3.346 in)

• 76884-71L02: 15 × 25 mm (0.591 × 0.984 in)

INSULATOR (Foam blocks)

Insulates components from contact. Can be used to fill space behind a panel.

• 73982-9E000: 45 mm (1.772 in) thick, 50 × 50 mm (1.969 × 1.969 in)

• 73982-50Y00: 10 mm (0.394 in) thick, 50 × 50 mm (1.969 × 1.969 in)

INSULATOR (Light foam block)

80845-71L00: 30 mm (1.18 in) thick, 30 × 50 mm (1.181 × 1.969in)

FELT CLOTHTAPE

Used to insulate where movement does not occur. Ideal for instrument panel applications.

• 68370-4B000: 15 × 25 mm (0.591 × 0.984 in) pad

• 68239-13E00: 5 mm (0.197 in) wide tape roll

The following materials, not found in the kit, can also be used to repair squeaks and rattles.

UHMW (TEFLON) TAPE

Insulates where slight movement is present. Ideal for instrument panel applications.

SILICONE GREASE

Used in place of UHMW tape that is visible or does not fit. Only lasts a few months.

SILICONE SPRAY

Used when grease cannot be applied.

DUCT TAPE

Used to eliminate movement.

CONFIRM THE REPAIR

After repair is complete, test drive the vehicle to confirm that the cause of noise is repaired by test driving the Nissan Ariya vehicle. Operate the vehicle under the same conditions as when the noise originally occurred. Refer to the notes on the Diagnostic Worksheet.

Diagnostic Worksheet

Inspection Procedure

Refer to Table of Contents for specific component removal and installation information.

INSTRUMENT PANEL

Most incidents are caused by contact and movement between:

1. Cluster lid A and instrument panel

2. Acrylic lens and combination meter housing

3. Instrument panel to front pillar garnish

4. Instrument panel to windshield

5. Instrument panel mounting pins

6. Wiring harnesses behind the combination meter

7. A/C defroster duct and duct joint

These incidents can usually be located by tapping or moving the components to duplicate the noise or by pressing on the components while driving to stop the noise. Most of these incidents can be repaired by applying felt cloth tape or silicon spray (in hard to reach areas). Urethane pads can be used to insulate wiring harness.

CAUTION:

Never use silicone spray to isolate a squeak or rattle. If the area is saturated with silicone, the recheck of repair becomes impossible.

CENTER CONSOLE

Components to pay attention to include:

1. Shifter assembly cover to finisher

2. A/C control unit and cluster lid C

3. Wiring harnesses behind audio and A/C control unit

The instrument panel repair and isolation procedures also apply to the center console.

DOORS

Pay attention to the following:

1. Finisher and inner panel making a slapping noise

2. Inside handle escutcheon to door finisher

3. Wiring harnesses tapping

4. Door striker out of alignment causing a popping noise on starts and stops

Tapping or moving the components or pressing on them while driving to duplicate the conditions can isolate many of these incidents. The areas can usually be insulated with felt cloth tape or insulator foam blocks from the Nissan Squeak and Rattle Kit (J-50397) to repair the noise.

TRUNK

Trunk noises are often caused by a loose jack or loose items put into the trunk by the customer.

In addition look for the following:

1. Trunk lid dampers out of adjustment

2. Trunk lid striker out of adjustment

3. Trunk lid torsion bars knocking together

4. A loose license plate or bracket

Most of these incidents can be repaired by adjusting, securing or insulating the item(s) or component(s) causing the noise.

SUNROOF/HEADLINING

Noises in the sunroof/headlining area can often be traced to one of the following:

1. Sunroof lid, rail, linkage or seals making a rattle or light knocking noise

2. Sunvisor shaft shaking in the holder

3. Front or rear windshield touching headlining and squeaking

Again, pressing on the components to stop the noise while duplicating the conditions can isolate most of these incidents. Repairs usually consist of insulating with felt cloth tape.

SEATS

When isolating seat noise it is important to note the position the seat is in and the load placed on the seat when the noise occurs. These conditions should be duplicated when verifying and isolating the cause of the noise.

Cause of seat noise include:

1. Headrest rods and holder

2. A squeak between the seat pad cushion and frame

3. Rear seatback lock and bracket

These noises can be isolated by moving or pressing on the suspected components while duplicating the conditions under which the noise occurs. Most of these incidents can be repaired by repositioning the component or applying urethane tape to the contact area.

UNDERHOOD

Some interior noise may be caused by components under the hood or on the engine wall. The noise is then transmitted into the passenger compartment.

Causes of transmitted underhood noise include:

1. Any component mounted to the engine wall

2. Components that pass through the engine wall

3. Engine wall mounts and connectors

4. Loose radiator mounting pins

5. Hood bumpers out of adjustment

6. Hood striker out of adjustment

These noises can be difficult to isolate since they cannot be reached from the interior of the vehicle. The best method is to secure, move or insulate one component at a time and test drive the Nissan Ariya vehicle. Also, engine RPM or load can be changed to isolate the noise. Repairs can usually be made by moving, adjusting, securing, or insulating the component causing the noise.
